MOSO® Bamboo X-treme® Varibo udendørs beklædning Grad profile


MOSO® Bamboo X-treme® Grad Cladding er massive brædder og profiler i forskellige bredder, til udvendige applikationer lavet af bambusstrimler, der er blevet komprimeret og termisk modificeret ved 200°C.

Denne unikke Thermo-Density®-proces giver Bamboo X-treme® den højest mulige holdbarhedsklasse i de relevante EU-normer, øger stabiliteten og densiteten og dermed hårdheden. MOSO® Bamboo X-treme® Grad Cladding er designet til installation på Grad aftagelige og skjulte installationssystem.

I modsætning til træprodukter kan dette materiale opnå brandmodstand uden imprægnering med dyre og miljøbelastende brandhæmmende produkter.

Den lukkede profil opnår brandklassificering klasse B-s1-d01) (EN 13501-1) med Grad installationssystemet. Som andet tropisk hårdttræ, når det udsættes for udendørs forhold, vil Bamboo X-treme® blive grå med tiden og skabe et meget naturligt udseende.

Varenummer Form Efterbehandling Overflade Stødsamlinger Effektiv vidde Dimensioner (mm)
BO-DTHT1180-BG Grad Ubehandlet Glat Nej 45 mm* 1850x45x20
BO-DTHT1190-BG Grad Ubehandlet Glat Nej 64 mm* 1850x64x20
BO-DTHT220-BG Grad Ubehandlet Glat Nej 119 mm* 1850x119x20
BO-DTHT540-1-BG Grad Closed Ubehandlet Glat Ja 136 mm* 1850x136x20


*) Effektiv bredde uden mellemrum mellem brædderne, afstand efter montering på Grad system 6 mm (undtagen lukket profil).

Bestil en prøvepakke eller book en produktfremvisning af MOSO bambus

Vi kigger gerne forbi og viser prøver, send os gerne en uforpligtende forespørgsel på salg@a2supply.dk

Du er også altid velkommen til, at kontakte os på tlf. +45 98 55 10 75 og høre nærmere om MOSO bamboo

Installation

  • Installation instructions are available from MOSO®: www.moso-bamboo.com/cladding/grad
  • MOSO guarantees the bamboo material and the mounting materials (fastener/screw) it supplies but does not guarantee the connection with other materials (such as sub frame joist/battens). It is the responsibility of the installer to make sure the used installation method matches such materials during the full lifetime of the product.
  • Store in a cool and dry place away from direct sunlight, and protected from weather influences, dirt and dust.
  • Installation instructions for the Grad installation system are available from Grad: www.gradconcept.com/en/media

Technical characteristics and certifications

  • Density: +/- 1150 kg/m3
  • Dimensional stability: length: + 0.1 %; width: + 0.9% (24 hours in water 20°C)
  • Resistance to Indentation - Mean value Brinell Hardness: ±9.5 kg/mm2 (EN 1534)
  • Reaction to fire: Class B-s1-d0 (EN 13501-1) 1)
  • Flame spread index: Class A (ASTM E84)
  • Thermal emittance: 0.81 (ASTM C1371) 2)
  • Solar Reflectance (SR): 0.32 (ASTM C1549) 2)
  • Solar Reflectance Index (SRI): Low 27, Medium 30, High 33 (ASTM E1980) 2)
  • Modulus of Elasticity: 13565 N/mm2 (mean value - EN 408)
  • Bending strength: 54.4 N/mm2 (characteristic value - EN 408)
  • Biological durability: Class 1 (EN 350 / CEN/TS 15083-2), simulated graveyard test / Class 1 (EN 350 / CEN/TS 15083-1)
  • Effectiveness against Blue Stain: Class 0 (EN 152)
  • Use Class: Class 4 (EN 335)
  • CO2 neutral: LCA report TU Delft (ISO 14040/44) (www.moso-bamboo.com/lca)
  • Environmental Product Declaration - EPD (EN 15804) (www.moso-bamboo.com/epd)
  • Contribution LEED BD+C - v4: MR 1, MR 2, MR 3 (FSC®), SS 7
  • v2009: MR 6, MR 7 (FSC®)
  • Contribution BREEAM: MAT 1, MAT 3 (FSC®), MAT 5 (HD)
  • Guarantee: 25 years


1) Tested on 18 mm thickness, without gaps between boards, with ventilation space behind boards.
2) Tested on 3 years weathered MOSO® Bamboo X-treme®.
